K type thermocouple wire cable list

K type thermocouple (Chromel+ / Alumel –)  is the most common type of thermocouple. It’s cheap, accurate, reliable, and has a wide temperature range.

K type Thermocouple wire cable always has a brown jacket ( Teflon FEP PFA or Fiberglass ) with Yellow and Red conductors. This wire is available in standard limits ±2°C or Special Limits ±1°C.

K type Thermocouple extension Wire is used to connect Thermocouples to Instrumentation.  It's accuracy is guaranteed over a limited temperature range. ( -40 ~ 221°F / -40 ~ 105°C )

It always has a YELLOW jacket with Yellow and Red conductors.

You can find some listed K type thermocouple wire,cable of our website below:

(Please click cable pics. to link the specification)

Model:PP-K-24F

Teflon PFA insulation with PFA out sheath

Model:PP-KK-30

Four wires, Teflon PFA insulation with PFA out sheath, IEC color standard

Model:PPB-K-24F

SS braid outside of PFA insulation and out sheath

Model:PPB-KK-24F

Four wires, SS braid outside of PFA insulation and out sheath, IEC color standard

Model:PTP-KKK-24F

six wires, copper tinned inner braid

Model:FF-K-20F,FF-K-24F

Teflon FEP insulation with FEP out sheath

Model:FF-KK-24F

four wires, Teflon FEP insulation with FEP out sheath, ANSI code

Model:FFB-K-24F

Teflon FEP insulation with FEP out sheath with SS braid

Model:GGB-K-24F

Fiberglass insulated with FG out sheath ,SS braid

Model:GB-KK-24F

Four wires, Fiberglass insulated with SS braid

Model:VV-K-24F

PVC-105C insulated with PVC out sheath

Model:FV-K-24F

Teflon FEP insulation with PVC out sheath

Model:PX-KK-24F

Four wires, Teflon PFA insulation with Silicone rubber out sheath

Model:KK-K-24F

Polymide insulation with Polymide out sheah
