RTD cable-Fiberglass-SSB-3cores

Product Item : Model:GGB-3SC-24F
3cores Fiberglass/FG/SS Braid
Stranded Copper silver-plated conductor 7*0.2mm
MOQ:500m
Delivery time: 15 days
Product description：This RTD sensors extension cable,wire is 3 cores copper silver-plated conductor with fiberglass insulation and SSbraid 24AWG.
INQUIRY

Material & Dimension Report
Product ID	GGB-3SC-7*0.20
Conductor Material	Cooper Wire plated Sliver
Single Inner Wire DIA	￠0.2mm
Inner Wire Construction	7 Inner Wires Stranded
Insulator Material	Fiberglass
Insulator Color	Red-Red-White
Cable Construction	3 Wires Stranded
Jacket Material	Fiberglass
Jacket Color	White
Over Braid Material	Stainless Steel
Insulated DIA	￠1.2mm
Cable DIA	￠3.5mm
Date:2016.03.16

Contact us for RTD catalogue and your customized Rtd sensor extension cable:

Whatsapp/Tel/Wechat: +86 1 3811300279

Email: sales@yiyuancable.com

Below are Yiyuan RTD cable Mfr. Model nos.

Model	Description	Temperature
GG	Fiberglass insulation + Fiberglass out sheath	400°C
GGB	Fiberglass insulation + Fiberglass out sheath+ SSB braid	400°C
F	Teflon FEP insulation	200°C
FF	Teflon FEP insulation with FEP out sheath	200°C
FTF	Teflon FEP + Copper tinned thread braid + FEP out sheath	200°C
FBF	Teflon FEP + SSB + FEP out sheath	200°C
FSF	Teflon FEP + Silver plated copper thread braid + FEP out sheath	200°C
FFB	Teflon FEP + FEP out sheath+ SSB braid	200°C
PP	Teflon PFA insulation with PFA out sheath	260°C
PAP	Teflon PFA + Al-foil + PFA out sheath	260°C
PTP	Teflon PFA + Copper tinned thread braid + PFA out sheath	260°C
PPTP	Teflon PFA + PFA+ Copper tinned thread braid + PFA	260°C
PBP	Teflon PFA + SSB + PFA out sheath	260°C
PPB	Teflon PFA + PFA out sheath+ SSB braid	260°C
VV	PVC insulation + PVC out sheath	105°C
FV	Teflon FEP+ PVC out sheath	105°C
VVB	PVC insulation + PVC out sheath+ SSB braid	105°C
XX	Silicone rubber insulation + Silicone rubber out sheath	180°C
XBX	Silicone rubber insulation + SSB+ Silicone rubber out sheath	180°C
FX	Teflon FEP +Silicone rubber out sheath	180°C
PX	Teflon PFA +Silicone rubber out sheath	180°C
KK	Kapton insulation + Kapton insulation	260°C
HH	High silica insulation + High silica out sheath	800°C

Description of RTD sensor and RTD extension cable

An RTD(Resistance temperature detectors) is a temperature sensor which measures temperature that the resistance of a metal changes with temperature. Actually, an electrical current is transmitted through a piece of metal (the RTD element or resistor) located in close to the area where temperature is to be measured. The resistance value of the RTD element is then measured by an instrument. This resistance value is then correlated to temperature based upon the known resistance characteristics of the RTD element.

We offer wide range of RTD extension cables with variety of insulation PVC, FEP, PFA, Silicon, Fiber glass,polymide, etc. Generally copper instrumentation cables are used to interconnecting RTD sensors with your process instrumentation. Resistance in all wires in RTD cables remain almost same to get the best results.
