High temperature wire -Silicone wire AGR

SILICON RUBBER/Silver-plated or tin-plated conductor,Solid or stranded
Rated voltage：300/500V
working temperature：-60～+200℃
Colours: red/yellow/blue/white/black/green/brown, etc
Product description：Model no.: AGR SILICON RUBBER/Silver-plated or tin-plated conductor,Solid or stranded Standard：Q/IRMV1－2008 Rated voltage：300/500V working temperature：-60～+200℃ Colours: red/yellow/blue/w
INQUIRY

High temperature wire and cable represent a vast range of wires which continue to perform at increased and elevated temperatures.

Yiyuan has designed a specialized family of wire and cable products that can take the heat. All of these high temperature cables can withstand applications in continuous heat.

Normal demands on high temperature cable is working under 200 °C and 250 °C we use teflon FEP/PFA and silicon to be the insualtion materials. But we still can produce high temperature cable reach up to 800°C with high silica material. If you need please contact us for specification!

Below is our high temperature cable infor. of types,size,cable structures,specifications,etc.

If you have special requirements please feel free to message or email us!

High temperature cable types:

Model	Product name	Temperature	Voltage
AF200	FEP copper silver-plated wire	200°C	600V
AF200X	FEP copper tinned wire	200°C	600V
AF250	PFA nickel or silver plated copper wire	250°C	600V
AFT250	PTFE silver, nickeled copper	250°C	600V
AGR	Silicon tinned copper wire	200°C	600V
AGRP	Silicon+Glass Fiber+Silicon	200°C	600V
AFF	FEP+FEP or PFA+PFA	250°C	300V
YGZ	Silicon+Silicon	200°C	300V
YGZF	FEP+ Silicon	200°C	300V
AFPF	PFA+braid+PFA	250°C	300V
YGZP	Silicon +braid+Silicon	200°C	300V
YGZPF	FEP +braid+Silicon	200°C	300V

High temperature cable structure:

Characteristics/uses：

It has excellent high temperature and low temperature resistance, excellent chemical stability, high voltage resistance, aging resistance and long service life. It is soft and easy to install.

It is widely used in lighting fixtures, household appliances, electric and thermal appliances, instrumentation, motor wiring and high temperature environment such as electronics, lamps and burners.

High temperature wire Specification, structure and technical parameters：

conductor nominal cross-section area （mm² ）	Conductor structure	Insulation thickness （mm）	outer diameter on the average （mm）	DC Resistance of Conductor at 20 Temperature 20 ℃ （Ω/km）	Packaging length （m）
conductor nominal cross-section area （mm² ）	Number/Single wire diameter	Insulation thickness （mm）	outer diameter on the average （mm）	DC Resistance of Conductor at 20 Temperature 20 ℃ （Ω/km）	Packaging length （m）
0.2	1 × 0.50	0.65	1.80	95	500
0.2	12 × 0.15	0.60	1.80	95	500
0.3	16 × 0.15	0.60	1.85	71.2	500
0.4	23 × 0.15	0.50	1.85	49.6	200
0.5	28 × 0.15	0.60	2.20	40.1	200
0.75	42 × 0.15	0.70	2.60	26.7	200
1.0	32 × 0.20	0.70	2.80	20.0	200
1.5	48 × 0.20	0.70	3.10	13.7	100
2.5	49 × 0.25	0.80	3.70	8.21	100
4.0	56 × 0.30	0.80	4.30	5.09	100
6.0	84 × 0.30	0.80	5.20	3.39	100
10	84 × 0.40	1.00	6.80	1.95	100
16	126 × 0.40	1.20	8.40	1.24	100
25	196 × 0.40	1.40	10.40	0.795	100
Note: According to the technical agreement between the two parties, products of other specifications can be produced.
