High
temperature wire and cable represent a vast range of wires which
continue to perform at increased and elevated temperatures.
Yiyuan
has designed a specialized family of wire and cable products that can
take the heat. All of these high temperature cables can withstand
applications in continuous heat.
Normal demands on high temperature cable is working under 200 °C and 250 °C we use teflon FEP/PFA and silicon to be the insualtion materials. But we still can produce high temperature cable reach up to 800°C with high silica material. If you need please contact us for specification!
Below is our high temperature cable infor. of types,size,cable structures,specifications,etc.
If you have special requirements please feel free to message or email us!
High temperature cable types:
|
Model
|
Product name
|
Temperature
|
Voltage
|
|
AF200
|
FEP copper silver-plated wire
|
200°C
|
600V
|
|
AF200X
|
FEP copper tinned wire
|
200°C
|
600V
|
|
AF250
|
PFA nickel or silver plated copper wire
|
250°C
|
600V
|
|
AFT250
|
PTFE silver, nickeled copper
|
250°C
|
600V
|
|
AGR
|
Silicon tinned copper wire
|
200°C
|
600V
|
|
AGRP
|
Silicon+Glass Fiber+Silicon
|
200°C
|
600V
|
|
AFF
|
FEP+FEP or PFA+PFA
|
250°C
|
300V
|
|
YGZ
|
Silicon+Silicon
|
200°C
|
300V
|
|
YGZF
|
FEP+ Silicon
|
200°C
|
300V
|
|
AFPF
|
PFA+braid+PFA
|
250°C
|
300V
|
|
YGZP
|
Silicon +braid+Silicon
|
200°C
|
300V
|
|
YGZPF
|
FEP +braid+Silicon
|
200°C
|
300V
|
High temperature cable structure:
It has excellent corrosion resistance, oil resistance, strong acid resistance, strong alkali resistance, strong oxidant, etc.
It has
excellent electrical insulation performance, high voltage resistance,
low high frequency loss, no moisture absorption, high insulation
resistance, excellent fire resistance, aging resistance and long service
life.
In the
electronic industry, it can be used for temperature compensation wire,
low temperature wire, high temperature heating wire, aging resistant
wire and flame retardant wire;
In the
household electrical appliances industry, it can be used for internal
wiring of air conditioner, microwave oven, electronic disinfection
cabinet, electric rice burger, electronic hot water bottle, electric
heater, oven, electric frying pan, lamp decoration, etc.
High temperature cable Specification, structure and technical parameters：
Core Number X Section
（mm² ）
|
Conductor structure
Number/Wire Diameter（mm）
|
Insulation
|
Sheath
|
|
Thickness
|
Outer diameter
|
Thickness
|
Outer diameter
|
|
2 × 0.12
|
7/0.15
|
0.20
|
0.85
|
0.25
|
2.20
|
|
3 × 0.12
|
7/0.15
|
0.20
|
0.85
|
0.25
|
2.30
|
|
4 × 0.12
|
7/0.15
|
0.20
|
0.85
|
0.25
|
2.60
|
|
5 × 0.12
|
7/0.15
|
0.20
|
0.85
|
0.25
|
2.80
|
|
6 × 0.12
|
7/0.15
|
0.20
|
0.85
|
0.25
|
3.10
|
|
7 × 0.12
|
7/0.15
|
0.20
|
0.85
|
0.30
|
3.15
|
|
10 × 0.12
|
7/0.15
|
0.20
|
0.85
|
0.30
|
4.0
|
|
12 × 0.12
|
7/0.15
|
0.20
|
0.85
|
0.30
|
4.20
|
|
19 × 0.12
|
7/0.15
|
0.20
|
0.85
|
0.35
|
5.0
|
|
2 × 0.2
|
7/0.20
|
0.20
|
1.0
|
0.25
|
2.50
|
|
3 × 0.2
|
7/0.20
|
0.20
|
1.0
|
0.25
|
2.60
|
|
4 × 0.2
|
7/0.20
|
0.20
|
1.0
|
0.25
|
2.90
|
|
5 × 0.2
|
7/0.20
|
0.20
|
1.0
|
0.25
|
3.20
|
|
6 × 0.2
|
7/0.20
|
0.20
|
1.0
|
0.30
|
3.60
|
|
7 × 0.2
|
7/0.20
|
0.20
|
1.0
|
0.30
|
3.60
|
|
10 × 0.2
|
7/0.20
|
0.20
|
1.0
|
0.30
|
4.60
|
|
12 × 0.2
|
7/0.20
|
0.20
|
1.0
|
0.30
|
4.70
|
|
19 × 0.2
|
7/0.20
|
0.20
|
1.0
|
0.40
|
5.80
|
|
2 × 0.35
|
19/0.16
|
0.25
|
1.30
|
0.25
|
3.10
|
|
3 × 0.35
|
19/0.16
|
0.25
|
1.30
|
0.25
|
3.20
|
|
4 × 0.35
|
19/0.16
|
|
